Motion Platforms

Motion Systems Qubic System - QS-H13 - Seat Mover

About QS-H13 - Challenger

The QS-H13 Challenger sets new standards in the world of motion systems for anyone looking for a compact and extremely quiet solution for their driving or flight simulator. The Qubic System Seat Mover - QS-H13, based on the same advanced technology as the QS-220 actuators, surpasses and eclipses all currently available seat motion solutions.
With smooth and precise movement across two axes (tilt/roll), it accurately simulates the forces experienced when braking, cornering in a car or performing sharp manoeuvres in an aircraft.

Link Video

Compact design that fits anywhere

The Qubic System Seat Mover is designed for people who have limited space for a simulator but still want to enhance their simulation experience without cluttering their environment.
The platform is equipped with industrial-grade components and exceptional structural rigidity, keeping it stable and providing a seamless connection to the vehicle so that the user can accurately feel details such as suspension behaviour. Installation is simple and requires no special craftsmanship or technical knowledge.
It is compatible with most aluminium cockpits without the need for additional brackets or drilling. Operates on 115/230 V, so no voltage converters are required. Just plug it in and get started. In addition, power consumption is low compared to other systems on the market.

Vibrations and haptics reserved for high-end products

Say goodbye to external devices such as bass shakers or other vibration generators for effects such as engine feedback. With this device, you get integrated functionality that delivers a wide range of low and high frequency vibrations. This allows you to better perceive various effects, improve your connection to the vehicle and become a better driver or pilot. These features are usually only found in high-end products and set this device apart from cheaper alternatives that lack vibration effects. They underline the high quality of the product.

Responsive precision without delay

One of the biggest challenges in the world of simulation is ensuring that a device can keep up with telemetry signals and accurately reproduce inputs without unnecessary delays. The QS-H13 has been designed in both hardware and software to ensure that there is no noticeable latency while driving. This advantage becomes even more apparent when using VR headsets, as the system integrates seamlessly with Qubic Manager's built-in motion compensation. This feature requires no additional setup – just plug it in and get started.

Silent and smooth operation

The system uses the same technology as the QS-220 and ensures extremely quiet operation, as it does not require gears or DC motors, which are common in other similar solutions on the market. Thanks to its silent operation, the simulator can be used in living spaces and late at night without disturbing other household members or neighbours. It delivers precise movements to accurately replicate the telemetry signals received by the simulation engine, improving vehicle control and enabling faster reactions, e.g. in the event of traction loss.

QS-H13 compatibility – designed for aluminium cockpits

The 2DOF Challenger is designed to fit perfectly with most aluminium cockpits and cockpits from other well-known brands. Its design makes it easy to install and compatible with a wide range of standard and optional equipment. It also works seamlessly with other devices from the Qubic system family, such as the QS-210, QS-220, QS-CH2 and QS-BT1. This makes it easy to expand your setup and ensures that all components work well together to provide an optimal simulation experience.


Technical specifications:

• Architecture 2 DOF
• Payload 130 kg
• Product weight: 33 kg
• Total length 417 mm | 16.41 in
• Total width 460 mm | 18.11 in
• Total height 231 mm | 9.09 in
• Storage temperature: +5 °C to +40 °C
• Supported effects: depending on the game
• Interface: USB
• Computer Windows PC
• Maximum length of USB cable: 3 m
• Maximum length of Motion Lock cable: 3 m
• Voltage range: 110C-240 VAC
• Frequency: 50-60 Hz
• Maximum current consumption: 10.43 A
• Maximum power consumption: 480 W

Scope of delivery:

• MAIN UNIT (QS-H13)
• USB cable
• External power supply
• Mounting adapter for aluminium cockpits
• Mounting adapter for BT1
• Motion Lock jumper and connection cable
• Qubic Manager (free licence included)

NOT INCLUDED (sold separately):

• Motion SDK – ForceSeatDI
• Motions SDK – ForceSeatMI | Motion Theater
• Seat angle
• Motion lock switch (emergency stop)

Important safety information:

The QS-H13 Challenger Seat Mover does not have any so-called E-brakes, which means that the seat can be moved by hand when switched off. If the centre of gravity of the seat is not above the centre point of the H13 (e.g. when mounting a BT1 at the rear), the seat may slowly move into one of the end positions (e.g. tilted backwards) after the power supply has been switched off or the optional emergency stop switch has been activated. Therefore, it is essential to ensure that the seat can always move freely and to mechanically lock the seat during installation work!





Qubic System - QS-CH1 Base Frame Set

About:

The QS-CH2 is a 2DoF motion platform that gives the SURGE and YAW motion for even better of feeling vehicle’s traction loss, breaking and accelerating. The motion system based on world’s fastest linear actuator’s technology provides incredible levels of vehicle feedback to the driver. This motion platform is suitable for Rally, Drift, GT and F1 simulations. The platform is fully
compatible with Qubic System 3DOF actuator’s set and QS-CH1 motion cockpit.

The system in our Showroom for testing: VIDEO

Link to Video: https://www.youtube.com/watch?v=GuoGMqHqqug

Key Features: What is included in the package:

• QS-CH2 Motion Platform
• QubicManager software download
• USB and power cables
• Nuts and Bolts required for assembly
• Product Manual

Please note:

• Price does not contain peripherals like: The Cockpit (The pictured QS-CH1 with the Qubic actuators is NOT included),PC computer, manipulators, game or simulation software, add-ons, accessories.
• Requires separate purchase of QS-MC6 (motion platform controler) if not already owned
• Production- / Shipping-Time aprox 10-14 weeks after your order.

Attention: Please ask us for the freight costs for your country before ordering, as the shipment may be made together with other Qubic products in a special transport box and the freight costs must therefore be calculated individually.

R2R-Addon emergency stop switch for Sim-platforms 2x power cold devices plus emergency stop ProSimu (if included) incl. mounting bracket

With the mushroom head slater you can mount the power supply of the Motion Platform comfortably and easily accessible on the cockpit. The emergency stop switch can be switched on and off during the running simulation and the Motion Platform switches on and off during the running game.

Attention: We offer this article, which is individually assembled, only in connection with cockpits, motion platforms and racing simulators purchased from us. No sale to customers who have not purchased simulators from us.

What's included:

• F2M adapter bracket in black satin powder-coated with screws for mounting on the cockpit.
• 3x emergency stop switch wired with safety plug and 3x power cable (for terminal devices)
• Mount option for ProSimu emergency stop switch (included with ProsSimu system)
• Manual

Assembly: The assembly is done by the customer himself. Since the switch is a current-carrying component (220V), the opening and assembly may only be carried out by trained personnel (electricians or similar). We accept no liability for damage caused by disregarding these instructions!

R2R-Addon Force2Motion Buttkicker

• External butlicker with control unit from the brand manufacturer
• incl. external sound card USB

Attention: This is an article which is only sold in connection with Ready-To-Race-Bundles. No single delivery!

Force2Motion Fanatec Pedal Lifter
With the Force2Motion Fanatec Pedal-Lifter the pedal plate of the original Fanatec Cockpit V2 can be raised by 6 cm to compensate the slightly raised seating position when using the Next Level Racing Motion Platform (Force2Motion Edition) and to achieve a more reclined driver position. The longitudinal adjustability of the pedals remains fully intact.

Scope of delivery:
2 pieces 280 mm long aluminium profiles black powder-coated with 4 correspondingly long toggle screws M6 for exchange against original toggle screws.

Cockpit, Next Level Racing Motion Platform Force2Motion Edition etc. not included!

Force2Motion RSeat N1 Adapter for Next Level Racing Motion Platform V3

What’s Included

• Force2Motion adapter for installing the Motion Platform in the RSeat N1 cockpit (RSeat Cockpit and Motion Platform not included)
• Manual (GERMAN)
• Attention: Due to the approx. 8cm higher seating position, the optionally available RSeat Keyboard stand can not be used without restrictions (legroom or height is not sufficient)

With the additional (!) Shifter extension for the RSeat N1 edition of the Next Level Motion Platform, you get an additional second adapter, so you can use an second original RSeat Shifter or similar on each side of the seat. The Shifter extension allows you to mount the shifter so far outward that the seat has enough room to move sideways through the Motion Platform.
The adapter plate is made of high quality aluminum and black powder coated. All necessary screws that can not be taken over by the original cockpit or the Motion Platform are included in the set. Attention: RSeat N1 Cockpit, RSeat N1 Edition of the Motion Platform, Handbrake, Shifter etc. are not included in the set! You only need this additional shifter extension if you want to mount two RSeat Shifter plates left and right at one time!

F2M Floor Plate Aluminium Cockpit 500x500 mm 500x500 mm

The F2M floor plate is installed in aluminium cockpits (e.g. Track Racer) and prevents the driver from stepping on the centre module of the NLR Traction Plus when the cockpit is mounted on it.

The plate consists of a 5mm thick folded aluminium sheet, powder-coated in black fine structure with corresponding holes for mounting on the aluminium profiles of the cockpit. The set is delivered with 6x screws and groove stones I-profile M8.

F2M Shifter Extension Short for Aluminium Cockpits

When installing a Next Level Racing V3 in an alloy cockpit, it can happen that the seat collides with a shifter mount on the alloy cockpit. For this purpose, a black anodised profile 80x40 shortened to 300 mm is offered, which replaces a standard profile (e.g. the 580mm one on the Trakracer 160).

Force2Motion adapter system Motion Platform Plus - extension carrier (top)

The upper frame (F2M adapter system Motion Platform Plus extension carrier) is used to accommodate the Wheel Stands of the NLR GTTrack Cockpit or the NLR Wheel Stand DD or the NLR Wheel Stand 2.0 and, together with a V3, to form the cockpit, which can then be equipped with one or two Motion Platform Plus. If this construct is to be mounted on a Traction Plus, you will also need the F2M base support.

And the upper frame can also (alone - without the lower carrier) "transport" the NLR FGT cockpit (with and without NLR seat) to a Motion Cockpit. Here you can integrate one or two Motion Platform Plus and operate the whole thing "solo" with the original floor supports from NLR. And you can even strap the system onto a Traction Plus system. Pretty crazy, but it works.

The complete description of the product including all possible combinations and the weight restrictions when using a Traction Plus system can be found in the following PDF.

The extension carrier (top) is needed for the following cockpits and motion platforms:

•  NLR GTTrack Wheel Stand on Traction Plus (base adapter required)
•  NLR Wheel Stand DD on Traction Plus (base adapter required)
•  NLR Wheel Stand DD without Traction Plus
•  NLR Wheel Stand 2.0 on Traction Plus (basic adapter required)
•  NLR Wheel Stand 2.0 without Traction Plus
•  NLR FGT Cockpit on Traction Plus (base adapter required)
•  NLR FGT Cockpit without Traction Plus

Scope of delivery:

• 2x side member with holes in specified colour
• 4x end plugs in black plastic
• 2x cross member top/outside with thread at the head sides
• 2x upper cross member for upper floor panel
• 2x top floor panel as step protection, bracing and mounting for various cockpits
• 1x top cross member for mounting rocker (original pivot bar when mounting only one Motion Plus platform)
• Slot nuts, screws, nuts and washers
• Instructions in German (English in preparation)

Dimensions: approx. 1370mm x 575mm x 60mm
Net weight: approx. 11 kg

Attention: This is not a toy and not a fully assembled product! The offered article is a kit for a motion cockpit. Manual skills and tools (including a ratchet set, Allen key, open-ended spanner set) are required for assembly. Operation is at your own risk. Make absolutely sure that no small children or pets can get near the moving parts!

Please note:

• Motion platforms, Traction Plus, V3 etc and cockpits not included. The article presented here only contains the parts described under "Scope of delivery".
• When mounting the system on an NLR Traction Plus system, please note the maximum payload of 235 kg (incl. driver)!
• There are various options for this article, which are shown in the compatibility matrix.

Attention: Once again, because it is so important: The maximum payload of the Traction Plus System is 235 kg including all components mounted on it such as Motion Platform V3, Motion Platform Plus, cockpits and controls and of course the driver himself. This weight must not be exceeded, otherwise the warranty for the Traction Plus system will be voided!


Force2Motion Adapter-System Motion Platform Plus - Additional Floor Plate Set Top

If the NLR-FGT-Cockpit (not FGT-ELITE) is used, an additional floor plate with stiffening profile is required. If only one Motion-Plus-Platform is used with the FGT-Cockpit, an 80x40 height compensation profile is required (see separate article).

The complete description of the product incl. all possible combinations and the restrictions regarding the weight when using a Traction Plus System can be found in the following PDF.

Force2Motion Motion Platform Plus Adapter System - Base Support (bottom)

With the F2M adapter system Motion Platform Plus it is possible to mount one or two Motion Platform Plus on the Traction Plus. Depending on the rider's weight (75-100 kg) and the mounted cockpit, an additional V3 can then be inserted into the cockpit.

The system consists of a lower (mandatory) and upper (optional) carrier system. Depending on the cockpit used, the upper carrier may or may not be required. The lower carrier is called the basic set and contains the floor plates 150mm and two cross members with bracing plates for Traction-Plus mounting. These parts are not or only partially needed for the upper beam (extension set), as the Motion-Plus platforms are located at this point. The upper support can also be used on its own to extend the Wheel Stands DD and 2.0 with one or two Motion-Plus platforms and a V3 to a Motion Cockpit.

The complete description of the product including all possible combinations and the weight restrictions when using a Traction Plus system can be found in the following PDF.

The basic carrier (below) is required for the following cockpits and motion platforms:

• NLR GT Elite Cockpit on Traction Plus (with Next Level Racing® GTElite Motion Adaptor Upgrade Kit).
• NLR FGT Elite Cockpit on Traction Plus
• NLR GTTrack Cockpit on Traction Plus
• NLR GTTrack Wheel Stand on Traction Plus (extension bracket required)
• NLR Wheel Stand 2.0 on Traction Plus (extension carrier required)
• NLR FGT Cockpit on Traction Plus (extension carrier required)
• NLR FGT Cockpit on Traction Plus (only extension carrier required - you do need the base support (bootom) for this!)
• Custom-built cockpits and third-party cockpits with Motion Plus on Traction Plus (Please enquire and seek advice individually!).

Force2Motion Motion Platform Plus adapter system - Motion Plus extension base support

With the basic carrier Motion Plus extension, the F2M adapter system Motion Platform Plus can be extended so that a second Motion Platform Plus can be used and mounted on the Traction Plus. Depending on the rider's weight (75-100 kg) and the mounted cockpit, an additional V3 can then be inserted into the cockpit.

The complete description of the product including all possible combinations and the weight restrictions when using a Traction Plus system can be found in the following PDF.

Scope of delivery:

• 1x Motion Plus cross member (for mounting a second Motion Plus platform) according to the selected colour or coating.
• 2x corner plates powder coating black fine structure
• Slot nuts, screws, nuts and washers
• Instructions in German (English in preparation)

Dimensions: approx. 105mm x 575mm x 60mm

Net weight: approx. 1,4 kg

Delivery times:

Delivery time for stock items (inventory items) is usually 2-5 days from receipt of order and payment. Combinations that are not in stock or are explicitly made due to a special colour request usually require 4-6 weeks delivery time.

Force2Motion Adapter System Motion Platform Plus - Additional Bracing Rocker Top FGT

When mounting only one Motion Platform Plus in combination with the NLR FGT cockpit, an additional stiffening profile is required for height compensation.

The complete description of the product including all possible combinations and the weight restrictions when using a Traction Plus system can be found in the following PDF.

Scope of delivery:

• Crossbar 80x40 for rocker Powder coating black fine structure
• 4x angle pieces for fastening Powder coating black fine structure
• 2x plugs 80x40
• Slot nuts, screws, nuts and washers
• Instructions in German (English in preparation)

Dimensions: approx. 80mm x 560mm x 120mm
Net weight: approx. 3,5 kg

The profile is only available in black powder coated.



Next Level Racing Motion Platform V3 - WEEE-Reg.-Nr. DE 11344112

Next Level Racing® V3 Motion Platform

• Next Level Racing® Platform Manager Software (Download)
• USB cable
• Power cable
• Steel side panels to directly bolt on to your Next Level Racing® GTultimate Cockpit, Next Level Flight Simulator or retrofit to your existing cockpit
• Manual (english)

An alternative to the Next Level Racing Motion Platform V3 is the Qubic Challenger H13 system. It has comparable installation dimensions (mounting points are practically the same as the V3), but offers more performance and precision. The control software is identical in terms of content.

Next Level Racing Motion Platform V3 KIT (Seat-Mover) - Details see options

Delivery time: The product is currently not available due to delivery problems with essential components. The next production batch has been announced for June 2024. It is strongly recommended to pre-order devices now, as it is expected that stocks will be sold in a very short time if available. In this case, we will accept an order without immediate payment (please select prepayment and specify "Payment on availability" in the order notes). As soon as the devices are available again, customers who have placed a pre-order will receive a corresponding message with a request for payment (incl. PayPal link). The pre-order only becomes binding once payment has been made.

With this article, an adapter kit for various cockpits can be optionally ordered at a preferential price. An SDK can also be added.

WEEE-Reg.-Nr. DE 11344112

• Next Level Racing® V3 Motion Platform
• Next Level Racing® Platform Manager Software (Download)
• USB cable
• Power cable
• Steel side panels to directly bolt on to your Next Level Racing® GTultimate Cockpit, Next Level Flight Simulator or retrofit to your existing cockpit
• Manual (english)

Next Level Racing Motion Plus Platform (Cockpit-Mover)

Note: We have developed an adapter system to run two Motion Plus platforms plus a V3 on a Traction Plus system. Further information: https://www.force2motion.de/en/motion-the-beast/force2motion-adapter-system-motion-platform-plus/

All good things come in threes: With the new Motion Plus Platform, Next Level Racing is expanding the Motion Eco System of the Motion Platform V3 and the Traction Plus System with a third component. Now it is also possible with the Next Level Racing systems not only to tilt the seat (Seat Mover) or to move the cockpit sideways to simulate oversteer and understeer (Cockpit Slider or Mover), but also to raise the entire cockpit. In contrast to other concepts (such as our Beast), the lifting is not realised by individual actuators (such as those of ProSimu or the Qubic system) but by one or two integrated modules that are mounted under the cockpit. The Next Level Racing cockpits GTTrack, GT- or FGT-Elite and even the FGT cockpit are supported as standard (with adapters if necessary), which until now had to remain completely outside the scope of the motion upgrade. But we will also support cockpits from other manufacturers in the future.

Leading Features:

• Full Cockpit Mover, simulating vehicle chassis motion with ultimate precision and accuracy
• Market leading technology to feel bumps, corners, rolls, gear shifts and vibrations for peak immersion
• Quick and simple installation, compatible with the Next Level Racing cockpits
• Commercially bulit, but perfect for home use with its compact design and low noise opertaion
• Compatible with all major racing and flight games for PC (Windows)
• 1 Module for 2-DOF and **2 modules for 3-DOF
• Adaotbale to the existing Next Level Racing Motion Ecosystem to continue taking racing to the next level
• Unique pivot bar included for single unit use setups
• Advanced VR Compensation Software to experience smooth prcise VR movement
• Ultra-low latency provides sharp and accurate movement throughout the chassis

F2M Adapter System Traction Plus for Aluminium Cockpits

With the F2M adapter system Traction Plus for aluminium cockpits it is possible to mount self-made cockpits or cockpits made of aluminium profiles on the Next Level Racing Traction Plus. IMPORTANT: The cockpits must have sufficient rigidity and stability so that they CANNOT bend in the middle when resting on the mounts of the Traction Plus system. The product consists of two adapters for the Traction Plus unit (front and rear identical) and a screw set. A cockpit or the Traction Plus System is not included.

RSeat S1 - Adapter Kit for Next Level Racing Motion Platform V3

Force2Motion adapter set for the installation of the Motion Platform in the RSeat S1 cockpit incl. lifter for wheel and pedal plate as well as for a shifter extension; With the Force2Motion adapters not only the Next Level Motion Platform is inserted into the S1 cockpit, but also the geometry of the seating position is adapted to the 8-10 cm higher seat surface. For this purpose, both the wheel mount and the shifter mount (analog flight mount) are raised by about 8-10 cm. The pedal plate is lifted by 4 cm. This virtually eliminates the higher seat height due to the Motion Platform mounted between the RSeat chassis and seat. The add-on parts are black anodized and of high quality. This means that neither the appearance nor the stability of the cockpit suffers, but the seat moves!

Scope of delivery

• Force2Motion adapter set for the installation of the Motion Platform in the RSeat S1 cockpit incl. shifter extension plate, lifter for wheel and pedal plate (RSeat S1 cockpit and NLR Motion Platform NOT included);

Force2Motion Adapterset for Next Level Racing Motion Platform V3 in Fanatec Cockpit

What’s Included

• Force2Motion adapter for installing the Motion Platform in the Fanatec cockpit (Fanatec Cockpit and Next Level Racing® V3 Motion Platform not included)
• Force2Motion adapter for mounting Fanatec handbrake on Fanatec shifter when using Motion Platform (handbrake, shifter and Fanatec Clamp not included)
• Manual (German)

Fanatec Cockpit and Next Level Racing® V3 Motion Platform not included!

F2M Adapter Set V3 Motion Platform for Aluminium Cockpits

With the F2M-Adapter Motion Platform V3 for aluminium cockpits it is possible to mount the Next Level Racing Motion Platform V3 in an aluminium cockpit e.g. of Trak Racer type 80 and 160. With the 160 cockpit (160mm overall height), the longitudinal profiles of the seat mount are omitted. With the 80 cockpit these are used (to obtain the necessary height / airspace for the V3). With the 160 cockpit the seat position increases by approx. 2 cm compared to the original seat, with the 80 cockpit by approx. 10 cm. For an inside width in the aluminium cockpit of 500mm.

The set consists of two aluminium brackets in black fine structure powder-coated for the V3 with 4 clamping screws. The inside of the bracket is equipped with a sliding strip so that the surface of the aluminium profiles is protected when the V3 is moved longitudinally.

Attention: When installing, make sure that there is sufficient air space for the fans of the V3 (approx. 2 cm distance to the floor and rear wall) and that the seat and, if applicable, a mounted butt-kicker can move freely without bumping into fixed parts or producing a crushing hazard for the hands. If a static shifter mount is used in the seat's movement area, it must be shortened so that the seat can move freely in all directions (this can be supplied by Force2Motion on request - see corresponding article).

Please Note: Cockpit and V3 not included.

Force2Motion RaceRoom 30x Adapter for Next Level Racing Motion Platform V3

What’s Included:

• Force2Motion adapter for installing the Motion Platform in the RaceRoom cockpits (RaceRoom cockpit not included, but optionally available)
• Force2Motion Seat-Adapter 345mm
• Next Level Racing® Platform Manager Software (Download)
• USB cable
• Power cable
• Manual (english)

Please note. Next Level Racing® V3 Motion Platform not inluded.
When using the Next Level Racing Motion Platform, we strongly recommend using the RaceRoom Stiffener Kits and the RaceRoom Seat Adjustment.

The kit is compatible with the RaceRoom RR3055 and RR3033 (for the cockpits  RR4055 and RR4027 see separate article). However, RaceRoom's 5.1 sound system cannot be used without modification, as the installation space for the subwoofer under the seat is used for the motion platform! The subwoofer must be placed manually outside the cockpit!

Next Level Racing Motion Platform SDK

Detailed product information can be found on the manufacturer's website at http://www.nextlevelracing.com/sdk/

Attention: The software is explicitly assigned to the serial number of your Motion Platform V3. It is not possible to return the software after ordering (revocation). The Next Level Racing Traction+ is also supported. However, the V3 is always licensed and the SDK can only be used when the V3 is switched on. A single operation of the Traction Plus with the SDK is not possible.

(Motion Platform not included)

Next Level Racing HF 8 Pro Haptic Feedback Gaming Pad

Main Features

• Over 200% Increase in Torque- Feel the difference in every turn, manoeuvre, and impact. With more than double the torque, the HF8 Pro delivers deeper, more forceful vibrations that hit harder and respond faster—enhancing immersion with every moment.
• Over 400% More Power– Built for intensity. With a massive 400% boost in motor power, the HF8 Pro provides stronger, more consistent feedback—delivering high-energy effects that stay powerful even during long, high-load gaming sessions.
• 60% Faster Motor RPM– Sharper. Quicker. More refined. A 60% increase in motor speed allows the HF8 Pro to deliver rapid, precise vibrations—from subtle surface textures to fast-paced impacts—with stunning clarity and accuracy.
• Real-Time Haptics: 15fps ➝ 75fps HFS Software– Experience ultra-responsive feedback like never before. The upgraded HFS software runs at 75 frames per second, providing near-instant haptic responses with ultra-low latency—so every sensation feels real and in sync.
• SIMAERO Mesh for Breathable Comfort– Stay cool under pressure. The HF8 Pro features our advanced SimAero™ mesh fabric, designed for airflow and comfort during extended sessions—so you stay dry, cool, and focused on the action.
• Upgraded High-Density Foam Padding– Built for endurance. Enhanced thicker foam ensures better pressure distribution and long-lasting comfort—perfect for immersive sessions in your racing or flight setup.

About

The Next Level Racing® HF8 Pro Haptic Gaming Pad is a breakthrough in immersive simulation, built for sim racing and flight enthusiasts who demand more. Featuring over 200% increased torque, 400% more power, and 60% faster motor speed, the HF8 Pro delivers high-fidelity feedback that responds with stunning accuracy—making every race, landing, and engine roar feel incredibly real.
With a new SIMAERO breathable mesh, upgraded high-density foam, and 75fps real-time haptics software, the HF8 Pro combines comfort with cutting-edge performance. Each of the eight individual motors can be fully customized to your preferences through the included HFS software or SimHub, giving you complete control over effects like RPM, braking, turbulence, and more—separately for racing or flight. Universally compatible with all major racing and flight cockpits, the HF8 Pro transforms your seat into a fully immersive simulator that reacts to every move with pinpoint precision.

Specifications

• Supported Height: 120cm – 210cm or 3'9" – 6'9"
• Supported Max Weight: 150kg or 331 lbs.
• Product Dimensions: (L) 119 cm x (W) 44 cm or (H) 4 cm /(L) 46.8 inches x W 17.3 inches x H 1.6 inches)
• Box Dimensions: 67 cm (L) X 13 cm (W) X 45 cm (H)/ 23.4 inches(L) x 5.1 inches (W) x 17.7 inches(H)
• Product Weight: 1.7 kg or 3.7 lbs.
• Boxed Weight – 2.3 kg or 5.1 lbs.
• Part Number – NLR-G006

What's in the box

• Next Level Racing® HF8 Pro Haptic Feedback Gaming Pad
• Digital assembly instructions and assembly videos are available here: http://bit.ly/nlr-instructions

Compatible products

• Next Level Racing® Racing Cockpits with seats
• Next Level Racing® Flight Cockpits with seats
• Next Level Racing® Seats
• Third Party Gaming Seats**
• Third Party Racing and Flight Seats**

** Please refer to the measurement of the HF8 Pro Gaming Pad to ensure that the product can fit correctly

Next Level Racing® ERS3 Haptic Feedback Sim Racing Seat

Leading Features

• Eight Integrated Haptic Motors: Seamlessly built into the seat for powerful, low-latency (75 FPS) positional feedback without compromising comfort.
• Equipped with HF8 Pro Technology: High-torque haptic motors deliver 200% more torque and 60% faster motor speed (400% more power) than the original HF8.
• Next Level Racing® HFS Software: Customise eight individual feedback zones for a fully immersive experience across racing and flight titles.
• ERS3 Endurance Design: SIMAERO Mesh fabric ensures maximum breathability and cooling comfort for long sessions.
• Ergonomic Racing Form: Cold-moulded foam, dual recliners, and precision lumbar support for users of all sizes.
• Universal Compatibility: Bottom-mount design fits most cockpits on the market; extra mount positions available with Next Level Racing® Universal Seat Brackets.

About

The Next Level Racing® ERS3 Haptic Feedback Sim Racing Seat combines two of the most acclaimed innovations in simulation — the comfort and ergonomics of the ERS3 Elite Seat and the haptic performance of the HF8 Pro. Developed from global community feedback, it represents the most accessible and affordable way to experience true integrated haptic feedback in a professional-grade seat.
“The next level of realism the Haptic Seats gives you is amazing. I particularly love the feelings through the gear shifts, ripple-strips and loss of traction. Makes it much easier to judge.” Alex Gardner, Professional Race Car Driver

Featuring the same advanced haptic technology as the HF8 Pro, the Next Level Racing® ERS3 Haptic delivers 200% more torque, 400% more power, and 60% faster motor speed than the original HF8 Haptic Feedback Pad. The eight embedded haptic motors are fully integrated into the seat frame, translating every corner, surface texture, and impact into detailed, real-time sensation while delivering direct and evenly distributed feedback. Built with SIMAERO Mesh fabric and cold-moulded foam, the ERS3 Haptic maintains the ERS3’s renowned comfort and posture support, making it ideal for long endurance sessions for sim racers and pilots alike.

Introducing the ERS3 and ES1 Haptic Sim Racing Seats

Video: https://youtu.be/j2qtTMFzYjE

Integrated Power and Comfort

Unlike traditional haptic pads, the ERS3 Haptic houses its motors within the seat structure for unmatched tactile precision and comfort. This fully integrated design eliminates shifting or vibration loss, ensuring every sensation — from tyre slip to turbulence — is transmitted directly through the seat. The SIMAERO Mesh fabric keeps you cool under pressure, while high-density foam maintains support through every lap, flight, or mission. Designed to accommodate larger body types and extended sessions, the ERS3 Haptic balances performance, strength, and ergonomic comfort for every user.

Customised Haptic Control

With full support for Next Level Racing® HFS software and SimHub integration, users can fine-tune each of the eight feedback zones to match their preferences. Control the strength and trigger behaviour of each motor — whether simulating engine RPM, road texture, braking, or turbulence. The HFS software runs at 75 frames per second for ultra-low latency feedback, while a built-in physical controller allows on-the-fly intensity adjustment with LED indicators for quick reference. For console* use, the 3.5 mm audio input transforms in-game sound into vibration feedback for racing, flight, or even music and VR experiences.
*Note: When using on console, haptic feedback is generated through audio-based vibration only. Individual motor control and telemetry-based effects are ONLY available on PC via HFS Software or SimHub.


NLR ES1 Haptic Feedback Sim Racing Seat

Leading Features

• Eight Integrated Haptic Motors: Seamlessly built into the seat for powerful, low-latency (75 FPS) positional feedback without compromising comfort.
• Equipped with HF8 Pro Technology: High-torque haptic motors deliver 200% more torque and 60% faster motor speed (400% more power) than the original HF8.
• Next Level Racing® HFS Software: Customise eight individual feedback zones for a fully immersive experience across racing and flight titles.
• True Bucket-Style Design: Contoured for stability and body support through corners and heavy braking.
• Side-Mount Ready: Compatible with industry-standard seat brackets for easy attachment.
• Durable Racing suede Fabric: Hard-wearing, PU molded foam racing suede fabric offers firm body support, reduced slippage, and comfort through long sessions.

About

The Next Level Racing® ES1 Haptic Seat combines the acclaimed ES1 bucket-style design with the proven haptic technology of the HF8 Pro, delivering a fully integrated seat built for high-performance simulation. Featuring the same eight high-torque haptic motors found in the HF8 Pro — delivering 200% more torque, 400% more power, and 60% faster motor speed — the ES1 Haptic provides detailed, real-time feedback that transforms every gear shift, curb strike, and surface change into true-to-life sensation.
“The next level of realism the Haptic Seats gives you is amazing. I particularly love the feelings through the gear shifts, ripple-strips and loss of traction. Makes it much easier to judge.” Alex Gardner, Professional Race Car Driver

Each motor is embedded directly into the seat shell, ensuring balanced, low-latency feedback without vibration loss, while the durable racing suede fabric and cold-moulded foam offer long-lasting comfort and stability during endurance sessions. With side-mount compatibility for precise positioning and easy integration into professional cockpits, the ES1 Haptic combines precision, control, and immersion—defining a new standard for competitive sim racing.

Video: https://youtu.be/j2qtTMFzYjE

Integrated Power and Comfort

Unlike traditional haptic pads, the ES1 Haptic integrates its eight high-torque motors directly into the bucket seat shell, delivering precise, low-latency feedback that follows every movement of the vehicle. This fully embedded design eliminates shifting or vibration loss, ensuring that every sensation — from tyre slip to kerb strike — is felt exactly where it happens. The durable racing suede fabric provides superior grip and comfort, while cold-moulded foam maintains firm support through long sessions. Designed for maximum body stability and endurance, the ES1 Haptic gives drivers the confidence and connection needed for competitive simulation.

Customised Haptic Control

With full support for Next Level Racing® HFS Software and SimHub integration, users can fine-tune all eight feedback zones for total control over their racing experience. Adjust motor strength, response, and trigger behaviour to replicate effects such as engine RPM, road texture, braking, and collisions. The HFS software runs at 75 frames per second, providing ultra-low latency and highly accurate feedback. A built-in physical controller allows quick intensity adjustments. For console* use, the 3.5 mm audio input converts in-game audio into dynamic vibration feedback for racing, flight, or multimedia experiences.
*Note: When using on console, haptic feedback is generated through audio-based vibration only. Individual motor control and telemetry-based effects are ONLY available on PC via HFS Software or SimHub.

Built to integrate and perform

The ES1 Haptic is designed for seamless integration with a wide range of professional simulator setups. Its side-mount compatibility allows precise positioning and angle adjustment with most industry-standard seat brackets, while the compact, lightweight design ensures easy installation across popular cockpits. The haptic system complements existing motion and tactile solutions, creating a unified feedback ecosystem for serious racers. With its rigid shell, ergonomic shape, and high-performance haptic technology, the ES1 Haptic delivers unmatched control, comfort, and immersion — built for the most demanding sim-racing environments.



Next Level Racing Elite Motion Adaptor Upgrade Kit

Leading Features

1. Compatible with the Next Level Racing® Elite Series Cockpits, Motion Platform V3, and Traction Plus Platform
2. Transforms the Elite cockpit into a motion compatible simulator*
3. Constructed with premium Carbon Steel and Aluminium Extrusion
4. Finished with high quality powder coating and anodised aluminium parts
5. Pre-drilled and machined for streamline installation

About


The Next Level Racing® Elite Motion Adaptor Upgrade Kit is a sim racer’s step towards full immersion, making the Elite* cockpit compatible with the Next Level Racing® Motion V3 and Traction Plus Platform. A combination of precision CNC-machining and laser cutting manufacturing process, as well as anodised and powder coat finish, gives the Elite Motion Adaptor Upgrade Kit the same level of quality and rigidity as expected from our Elite range of simulation products. *Please check Motion Products to see if your cockpit requires the Elite Motion Adaptor Upgrade Kit as not all Elite cockpits require this add-on

Force2Motion adapter for Qubic BT1 Belt-Tensioner to NLR Motion Platform V3



In combination with the BT1V3 adapter developed by us, the Seat Belt Tensioner can be mounted on a Next Level Racing V3 as well as on practically any other seat console. The function of a seat slider for longitudinal adjustment of the seat is fully retained.

Watch the video (sorry German version only)

Scope of delivery:

• 1x Force2Motion adapter for Qubic BT1 Belt-Tensioner
• Screw set

Motion platform, belt tensioner, seat slider etc. NOT included.
Attention: Does not fit the Qubic CH1!

Force2Motion Bundle Qubic Systems BT1

The bundle contains:

• Motion-Systems Qubic System - Belt Tensioner BT1
• Motion-Systems Qubic System - Motion Lock für Seat Belt Tensioner
• Sicherheitsgurt 6-Punkt schwarz
• Force2Motion Adapter für Qubic BT1 Belt-Tensioner an NLR Motion Platform V3 Motion Platform V3, Force2Motion Seatframe oder andere Sitzkonsolen

Price advantage when ordering all four items without modification in the basket!

Qubic System - QS-220 Motion System - Set with 2 Actuators and 1 Power Cabinet

About QS-220

Linear actuator technology by Motion Systems allows to develop highly realistic applications with detailed motion textures, velocity, suspension interaction feedback, engine vibrations, tactile feedback, haptic system and vehicle dynamics. Innovative technology, modular and compact design, as well as the quiet operation makes the QS-220 as a perfect motion base not only for professional application but also for home users in various types of cockpits. Additional sets of QS-220 can be configured as a 4 and 6 actuated system to provide 3 / 4 / 6 DOF using dedicated cockpits from Qubic System product line.

By using dedicated software Qubic Manager the user can use several sets to create the most realistic simulation that immediately responds to onscreen situations to deliver real life experience in gaming or VR
applications. Motion Systems is a global leading motion platforms brand for professionals and the most demanding home users. For over 10 year the company has been designing and providing bespoke motion solutions for industry and cutting edge technology for racing and flight simulation.

Fast Facts - Hardware:

Patent pending technology of QS-L1 linear actuators from Qubic System Line allows to develop highly realistic applications with detailed effects from simulation telemetry. Motor drivers have
been designed by Motion Systems company to do just one job, to control motors in vehicle simulator applications and they are exceptionally good at it.

Included power cabinet (control module) QS-SB2 is responsible for the power distribution and communication to handle telemetry signal processing where motion controller dispatches the commands
to drivers which parse the incoming command as soon as the command arrives. Control module sets the motion and vibration cues for each single actuator. The driver works with both 115V and 230V power
network without any adapters or voltage converters.

General specification of QS-220 set:

• Architecture: 2 / 3 / 4 / 6 DOF (depending on user configuration and number of modules)
• Actuator stroke: 100 mm | 3.93 in
• Maximum velocity:
  • Q-Mode (230V): 800 mm/s
  • Performance Mode (115V/230V): 400 mm/s
  • Heavy Duty Mode (115/230V): 300 mm/s
• Maximum acceleration:
  • Q-Mode (230V): 0.8G*
  • Performance Mode (115V/230V): 0.7G*
  • Heavy Duty Mode (115/230V): 0.4G*
  • *value of acceleration is limited for safety reasons.
• Recommended payload in 3DOF (2x QS-220) configuration:
  • Q-Mode: 200kg
  • Performance Mode: 250kg
  • Heavy Duty Mode: 350kg
• Maximum control frequency: 1000 Hz
• Vibrations frequency range: 0-100 Hz
• Latency: <8 ms
• Product weight: 30 kg | 66 lb
• Total length: QS-L1: 90 mm | 3.55 in, QS-SB2: 385 mm | 15.16 in
• Total width: QS-L1: 90 mm | 3.55 in, QS-SB2: 300 mm | 11.81 in
• Total height: QS-L1: 553-653 mm | 22-26 in, QS-SB2: 88 mm | 3.46 in
• Cable length (QS-L1 actuator - QS-SB2 Power cabinet): 1150mm | 45.2 in
• Power supply requirements: 115/230 VAC Single Phase
• Average power consumption in 3DOF configuration:
  • Q-Mode: 260W (230V)
  • Performance Mode: 280W (230V), 270W (115V)
  • Heavy Duty Mode: 436W (230V), 462W (115V)
• Peak current for breaker specification in 3DOF configuration:
  • Q-Mode: 5.17A (230V)
  • Performance Mode: 4.55A (230V), 7.35A (115V)
  • Heavy Duty Mode: 5.88A (230V), 9.89A (115V)
• Connection: USB

Fast Facts - Software:

Even most advanced hardware is nothing without good software. Qubic Manager by Motion Systems company is professional and specialized software for the platform and is "click and play" compatible with
all major racing and flight titles on PC and constantly updated to support new applications as they are released. Gives user possibilities of motion adjustments, motion post-processing, extensive diagnostic or
easy and fast use of predefined profiles. The Qubic Manager is a powerful engine, yet it’s simple to use meaning you can adjust levels of motion, bumps, roll and pitch with a click of a button.

Qubic Manager software license is free-of-charge.

Few main features:

• Over 80+ already integrated and supported racing games and professional simulation applications.
• Included VR Headway technology uses advanced mathematic formulas to calculate necessary compensation and applies it to the VR headset at runtime. It eliminates platform movements from the VR tracking system causing your experiences to be more immersive, authentic and has huge impact on VR sickness compensation.
• The motor control algorithm has been developed to be used strictly in simulation application. The positioning signal is analyzed and preprocessed directly by the driver, so it is possible to change all driver parameters at basically zero cost (time / latency). Drivers parse the incoming command as soon as the command arrives. It also allows to append different types of vibrations (per actuator) on driver level.
• Motion sickness compensation thanks to telemetry data provided in real time directly by the game’s engine and immediately injected to the hardware to perform.
• Equipped with Tactile Audio Based Feedback System that can use tactile trans-ducers (Buttkicker) connected to a seperate sound card to generate additional effects on your cockpit (Buttkicker and additional Soundcard not included - available seperatly).
• Thanks to having full control of the technology Motion Systems company can change control algorithm source code, introduce new parameters and features without waiting for 3rd party vendors. Simple software update can introduce new features to the customers.
• Motion SDK (FSM or FSDI) for software developers is also available as an extra option. That powerful interface allows to add a motion platforms support to any application or game.
• … and many more!

What is included in the package:

• QS-220 motion set:
  • 2x QS-220 - linear actuator with cup holder
  • 1x QS-SB2 - power cabinet (control module)
  • 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
  • 1x Power cable - 1 pcs of 1,8m long cable for EU market / or 1 pcs of 2m long cable for USA market
  • 2x QS brackets for mounting on aluminum profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)

What else is needed to operate the set:

• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS-220 (not included - see seperate product)
