Cockpit-Mover

Qubic System - QS-CH1 Base Frame Set

About:

The QS-CH2 is a 2DoF motion platform that gives the SURGE and YAW motion for even better of feeling vehicle’s traction loss, breaking and accelerating. The motion system based on world’s fastest linear actuator’s technology provides incredible levels of vehicle feedback to the driver. This motion platform is suitable for Rally, Drift, GT and F1 simulations. The platform is fully
compatible with Qubic System 3DOF actuator’s set and QS-CH1 motion cockpit.

The system in our Showroom for testing: VIDEO

Link to Video: https://www.youtube.com/watch?v=GuoGMqHqqug

Key Features: What is included in the package:

• QS-CH2 Motion Platform
• QubicManager software download
• USB and power cables
• Nuts and Bolts required for assembly
• Product Manual

Please note:

• Price does not contain peripherals like: The Cockpit (The pictured QS-CH1 with the Qubic actuators is NOT included),PC computer, manipulators, game or simulation software, add-ons, accessories.
• Requires separate purchase of QS-MC6 (motion platform controler) if not already owned
• Production- / Shipping-Time aprox 10-14 weeks after your order.

Attention: Please ask us for the freight costs for your country before ordering, as the shipment may be made together with other Qubic products in a special transport box and the freight costs must therefore be calculated individually.

Next Level Racing Motion Plus Platform (Cockpit-Mover)

Note: We have developed an adapter system to run two Motion Plus platforms plus a V3 on a Traction Plus system. Further information: https://www.force2motion.de/en/motion-the-beast/force2motion-adapter-system-motion-platform-plus/

All good things come in threes: With the new Motion Plus Platform, Next Level Racing is expanding the Motion Eco System of the Motion Platform V3 and the Traction Plus System with a third component. Now it is also possible with the Next Level Racing systems not only to tilt the seat (Seat Mover) or to move the cockpit sideways to simulate oversteer and understeer (Cockpit Slider or Mover), but also to raise the entire cockpit. In contrast to other concepts (such as our Beast), the lifting is not realised by individual actuators (such as those of ProSimu or the Qubic system) but by one or two integrated modules that are mounted under the cockpit. The Next Level Racing cockpits GTTrack, GT- or FGT-Elite and even the FGT cockpit are supported as standard (with adapters if necessary), which until now had to remain completely outside the scope of the motion upgrade. But we will also support cockpits from other manufacturers in the future.

Leading Features:

• Full Cockpit Mover, simulating vehicle chassis motion with ultimate precision and accuracy
• Market leading technology to feel bumps, corners, rolls, gear shifts and vibrations for peak immersion
• Quick and simple installation, compatible with the Next Level Racing cockpits
• Commercially bulit, but perfect for home use with its compact design and low noise opertaion
• Compatible with all major racing and flight games for PC (Windows)
• 1 Module for 2-DOF and **2 modules for 3-DOF
• Adaotbale to the existing Next Level Racing Motion Ecosystem to continue taking racing to the next level
• Unique pivot bar included for single unit use setups
• Advanced VR Compensation Software to experience smooth prcise VR movement
• Ultra-low latency provides sharp and accurate movement throughout the chassis

Next Level Racing Motion Platform SDK

Detailed product information can be found on the manufacturer's website at http://www.nextlevelracing.com/sdk/

Attention: The software is explicitly assigned to the serial number of your Motion Platform V3. It is not possible to return the software after ordering (revocation). The Next Level Racing Traction+ is also supported. However, the V3 is always licensed and the SDK can only be used when the V3 is switched on. A single operation of the Traction Plus with the SDK is not possible.

(Motion Platform not included)

Motion-Systems Qubic System - CH2-210.3DOF.BT1 Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-210 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market
• 4x QS brackets (set of 2) for mounting on aluminium profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - CH2-220.3DOF.BT1 Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-220 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market / or 1 pcs of 2m long cable for USA market
• 4x QS brackets (set of 2) for mounting on aluminium profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - CH2.220.3DOF.BT1.FGT.SET Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-220 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market
• 4x QS brackets (set of 2) for mounting on aluminum profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories
• Force2Motion Adapter for Qubic BT1 Belt-Tensioner
• F2M-Adaptersystem FGT-Elite-Qubic
• Next Level Racing FGT 160 - Wheel Plate Edition

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - CH2.210.3DOF.BT1.FGT.SET Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-210 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market
• 4x QS brackets (set of 2) for mounting on aluminum profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories
• Force2Motion Adapter for Qubic BT1 Belt-Tensioner
• F2M-Adaptersystem FGT-Elite-Qubic
• Next Level Racing FGT 160 - Wheel Plate Edition

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

F2M adapter system FGT-Elite-Qubic

With the F2M adapter system FGT-Elite-Qubic it is possible to mount the Qubic actuator system QS210 or QS220 on the Next Level Racing FGT Elite cockpit

The F2M base plate is mounted under the Next Level Racing FGT Elite cockpit and closes off the cockpit at the bottom. The control units for the Qubic QS210/QS220 can be mounted on the underside of the plate using pre-drilled holes.

With the extended actuator brackets also included, the actuators can be mounted on the cockpit offset by 40 mm so that they do not collide with the pedal plate of the FGT-Elite/FGT 160.

Attention: When mounting the system on a Qubic CH2, the Qubic CH2 cockpit adapter set is also required (see https://www.force2motion.de/de/cockpit-adapter-set-qubic-ch2.html)

The plate consists of a 5 mm thick folded aluminum sheet, powder-coated in black fine structure, with corresponding holes for attachment to the aluminum profiles of the cockpit. The set is supplied with screws and I-profile M8 slot nuts. The actuator brackets consist of black powder-coated brackets with corresponding holes, e.g. for the FGT-Elite cockpit (80/100 and 160 aluminum profiles).

Scope of delivery:

• Base plate black powder-coated 5 mm drilled for NLR FGT Elite
• T-nuts
• screws
• 4x double sets of actuator brackets for wider actuator mounting - A double set consists of two identical / mirrored brackets.
•  Any controllers and accessories shown are NOT included!

F2M Adapter System FGT-Elite-Qubic – Base Plate

The F2M Adapter System FGT-Elite-Qubic allows the Qubic actuator system QS210 or QS220 to be mounted on the Next Level Racing FGT Elite cockpit.

Please refer to the relevant product description for the complete system. This item contains only the base plate with the necessary screws and slotted nuts





F2M Adapter System FGT-Elite-Qubic – Bracket Set 4x2

The F2M Adapter System FGT-Elite-Qubic allows the Qubic actuator system QS210 or QS220 to be mounted on the Next Level Racing FGT Elite cockpit.



The F2M base plate is also available separately as an option; this not only provides the aluminium cockpit with a sturdy base but also allows the Qubic actuator control units to be mounted from below. This plate is not included in this set (see separate item!





The F2M-Qubic Actuator Adapter System FGT is designed for mounting Qubic 210/220 actuators on cockpits such as the Next Level Racing FGT and FGT160 series or similar aluminium square-profile cockpits.

Here, there are still attachments on the outer side of the longitudinal beams (such as the struts for the pedal plates, which protrude sideways beyond the longitudinal profiles). This means that the standard Qubic actuator brackets cannot be fitted at this point. The F2M-Qubic Actuator Adapter System FGT consists of 8 identical brackets (2 per actuator), with the actuator mounted 40 mm offset outwards. This creates the necessary space to ensure the actuators do not collide with the protruding mounting parts.





The brackets have various mounting holes (some of which are slotted) to compensate for manufacturing tolerances and to allow them to be fixed at different heights or to aluminium longitudinal profiles of varying heights (80 to 160 mm with 2 to 4 slotted rails). Both the QS210 and QS220 actuators can be used (no mixed configuration!).

When mounting the entire cockpit on a Qubic CH2, ensure that the longitudinal distance between the front and rear actuators is 1114 mm, as specified in the Qubic manual. This is achieved by adjusting the adapter brackets via the slotted holes.

The F2M base plate is also available separately as an option; this not only provides the aluminium cockpit with a sturdy floor but also allows the Qubic actuator control units to be mounted underneath. This plate is not included in this set (see separate item)!





The entire system is compatible with the Qubic CH2.



Note:



The Qubic Adapter Set for Wider Cockpits is required to mount the wider cockpits onto a CH2. This is included with the CH2 for units shipped from May 2025 onwards. For units purchased prior to this date, the set must be purchased separately.











Qubic System - QS-S25 Base-Set 6DOF

About:

The QS-S25 is an advanced motion cockpit, designed for the most demanding racers who are looking for a professional simulation experience on high top level. The motion system based on patent pending linear actuator’s technology allows a much stronger sensation range such as under steer, loss of grip or overloading during brake clearly blurring the difference between reality and virtual environment. Due to the combination of dedicated accessories and the QubicManager software, the 6DoF motion platform provides drivers with an extreme experience like in a real race or during the ultimate flights.

The QS-S25 consist of 6 degrees of freedom (surge, sway, heave roll, pitch and yaw) which determined a position and movement of a car. The combination of the high precision technology of the motion system with QubicManager functionalities guarantees perfectly reflect the situations in the selected game. Further the impressive dynamics and high performance of QS-S25 motion system means that the racing simulation has never been at such a top high.

The original machine’s design based on modular and reconfigurable sets of actuators can be used in various racing or flight applications. Compact design and small footprint fits to the medium size gaming rooms, VR centers, and training facilities for professional drivers and -of course: in the private man cave.

The platform is compatible with the selected Virtual Reality headsets on the market, which makes QS-S25 open to a new possibility in combining technologies. QubicManager uses advanced mathematic formulas to calculate necessary compensation and applies it to the VR headset at runtime. It eliminates platform motions from the VR tracking system, causing your experiences to be more immersive and authentic.
