Motion-Systems Qubic System - Belt Tensioner BT1 - Multi-purpose, dual channel, direct drive seat belt tensioner

Note: All BT1 units supplied by us have the ‘new’, quieter power supply unit. Please note: Delivery does not include an IEC power cable – please order separately (only available from us for German and compatible sockets with type E+F safety plugs) or purchase one yourself that complies with the standards in your country (See image ‘Power Requirements’ for requirements)!

The Polish manufacturer Motion Systems, which has developed the “Qubic System” motion platforms among other things, has launched a new sensation: the QS-BT1 belt tensioner.

And we are rather proud of this development ourselves, as Force2Motion was a driving force behind the creation of this add-on. With input from the racing and flight sim communities, we have persistently campaigned for Motion Systems to build what we consider to be an indispensable extension for the Qubic systems. And now Motion Systems has unveiled this product, which can also be fitted to many stand-alone cockpits without motion. And of course, it’s a great addition for those who already have ‘everything’. Well done, guys!

In combination with the BT1V3 adapter we developed, the Seat Belt Tensioner can be mounted on both a Next Level Racing V3 and virtually any other seat console. The function of a seat slider for longitudinal seat adjustment is fully retained.

Watch the video (sorry German version only)

More info and photos: https://qubicsystem.com/product/qs-bt1/# - Please be sure to follow the instructions on installation (seat height, belt openings on the seats) etc.!

About:

Powered by the same technology as the stunning QS-220, the QS-BT1 is a multi-purpose dual channel direct drive seatbelt tightener that enhances immersion in racing simulations like no other device in its class and price range. It not only complements the force feedback of the direct drive steering wheels, but also enhances the overall experience of the already highly immersive QS motion platforms and can even be used as a standalone, independent device if required.

Simulation of braking, lateral acceleration, cornering at high speed, wheel lock and loss of traction are among the key features of QS-BT1. Asymmetric engine vibrations and road effects such as rumble strips are also available for games that support them. Although QS-BT1 was mainly developed for racing simulations, with its 200 N force per channel it can also be successfully used in flight simulators to give you the feeling of gigantic forces during high acceleration manoeuvres.

Specifications:

• Power source: 4A/115VAC, 2A/230VAC
• Rated power: 321 W
• Inrush current: 20A/115VAC, 40A/230VAC
• Protection class: 1
• Interface: USB
• Number of independent channels (seat belts): 2
• Tensile force: 20.5 kg/45 lbs/200 N per channel
• Storage temperatures: +4°C to +45°C
• Full performance temperatures: +5°C to +35°C
• Computer compatibility: Windows PC
• Supported effects: Depending on the game
• Multifunctional RGB
• Maximum length of USB cable: 3m
• Maximum length of motion lock cable: 3m (motion lock optional)
• Compatibility with motion platforms: QS, PS, HS [1]

Dimensions:

• Main dimensions: 561 x 99 x 138 mm / 22.13 x 3.90 x 5.43 inches
• Weight of the main unit: 12 kg / 26.46 lbs
• Weight of the power supply unit: 2.8 kg / 6.17 lbs
• Dimensions of the packaging box: 660 x 255 x 180 mm / 25.98 x 10.04 x 7.09 in
• Weight of the packaging box: 18kg / 39.68 lbs

Scope of delivery:

• 1x two-channel seat belt tensioner
• 1x power supply unit
• 1x cable set (without power cable!)
• 1x set of screws
• 1x universal bracket for aluminium profile

Optional accessories (recommended):

• Emergency stop switch (motion lock) - is not required if other Qubic systems are present, as the system can be controlled via an (existing) motion lock switch.
• Note: All BT1 units supplied by us have the ‘new’, quieter power supply unit. Please note: Delivery does not include an IEC power cable – please order separately (only available from us for German and compatible sockets with type E+F safety plugs) or purchase one yourself that complies with the standards in your country (See image ‘Power Requirements’ for requirements)!

Note: For the use of seat movers (such as the NLR Motion Platform V3), the QS-BT1 can only be installed on the upper frame of the motion platform near the pivot point and reduces the permissible user weight. A multi-point harness is required and is not included in the scope of delivery.



Force2Motion 8DOF - Motion Simulator - The Beast - FGT Elite Edition (Seat-Mover and Cockpit-Mover)

The ultimate combination of Seat-Mover and Full-Motion-Cockpit with Traction Loss

Attention: This is a bundle which only consists of the cockpit and the necessary motion systems incl. adapters. You also need a PC, monitor(s), pedals etc.. For this purpose, there is a Built-To-Order article in the shop that contains all possible options that you can add or remove.

With the new FGT ELITE cockpit from Next Level Racing we have now found the third basis for our "Beast". Due to its construction with high-quality aluminium profiles, it fulfils several requirements that we have for a cockpit that is to be modularly expanded into a fully movable motion system:

• High quality and stability
• Accurate fit and a wide range of adjustment possibilities
• Modularity
• Compatibility with the Motion Platform V3 and the Traction Plus System as well as the ProSimu System

Assembly time: The complete assembly of the beast takes 2-3 days if you know what you are doing and read and understand the manual. If you don't feel like reading our manual (please download and read under "Documents" before buying) and the manuals for the individual products, have two left hands or are simply too impatient, then please use our assembly service (conditions on request) or leave the kit alone! This prevents frustration on both sides ;-) !

Force2Motion 8DOF - Motion-Simulator - "The Beast - Fanatec Edition" (Seat-Mover and Cockpit-Mover)

The ultimate combination of Seat-Mover and Full-Motion-Cockpit with Traction Loss

Attention: This is a bundle, which only consists of Cockpit and the required motion systems incl. adapter. You need an additional PC, monitor(s), pedals etc. There is a Built-To-Order article in the shop, which contains all possible options you can add or remove.

Our innovative Force2Motion 8DOF cockpit, exclusively manufactured in this combination, combines the Fanatec Clupsport V2 Cockpit with Motion Platform V3 (Seat Mover) and the Traction Plus system (for oversteer and understeer effects) from Next Level Racing with the Cockpit Mover based on the ProSimu T1000 4M. As the "cream on top", a butt kicker is mounted, which transfers the vibrations from the engine, speed limiter and curb effects tactilely into the seat and thus onto the driver's body.

This turns the system into the ultimate racing and/or flying cockpit with 8 DOF. This product idea arose from the idea of putting together a complete cockpit with all conceivable options for our showroom in order to show our customers the respective effects of the individual motion systems on one system. After we had gained sufficient experience with the prototype, we completely redesigned the adapter system for combining the two worlds and had it manufactured in Germany. The adapter system is so modular that it is 100% compatible with the Next Level Racing Traction Plus system and can therefore be installed as an add-on between the Fanatec Clupsport V2 Cockpitt and Traction Plus. The adapter system can also be used to mount other cockpits on the Next Level Racing Traction Plus system.

The Beast: All-In-On for testing in our showroom (see here the NLR-Version)

Fast Facts:

• Fanatec Clupsport V2 Cockpit with 4DOF plus Next Level Racing Motion Platform (Seat-Mover) with 2 DOF and Traction Plus (2 DOF)
• 8 actuators plus Buttkicker
• Fanatec Clupsport V2 Cockpit cockpit with seat adjustment and Force2Motion-Adaptersystem
• Racing seat
• Safety belts
• Force2Motion adapter systems Size X
• All necessary electronics, cables and screws including cables (power supply, signal converter USB)
• Plastic housing and steel/alu frame
• Very resistant paint (colour powder heated to 200 ° C on the structure)
• Made of square/round tubes, ultra-precise laser cutting, allows maximum rigidity.
• Compatible with many accessories and devices: Thrustmaster, Fanatec etc. (not included)
• Power supply: Standard Schuko plug 110-240V - Power consumption approx. 500 Watt
• Space requirements (footprint): length approx. 200 cm x width 120 cm (+ space for entry) x height 170 cm (upper edge of seat) - available width between actuators: 64 cm (max. cockpit width)
• Weight (without cockpit, motion platforms and controls):
  • Static adapter incl. actuator holder and screws: 9.2 kg
  • Dynamic adapter incl. screws (without actuators): 8.5 kg
  • Actuators per piece: 8,3 kg
  • Adapter plate (optional): 6.8 kg
  • The recommended driver weight is 80-100 kg (depending on the equipment of the overall cockpit - official payload of the Traction Plus System is 235 kg)
• Supported Games: Details see Simtools and Platform-Manager
  • Software is constantly updated as new games are released; Not every software title is equally well supported by every motion system.

Windows - PC required ! No support for Playstation, Xbox and other consoles! - Software (Simtools) included!

For details of the Next Level Motion platform see the corresponding article description

Attention: This is not a toy and not a ready assembled product! The offered article is a kit for a motion cockpit. For assembly, manual skills and tools (including ratchet set, Allen spanner, open-end spanner set and socket spanner 22 or 24mm) are required. For the drive, actuators from the industrial control system are used, which are not designed for home use. The installation and connection of the electrical components may only be carried out by appropriately qualified persons. Operation is at your own risk. Make absolutely sure that no small children or pets can get near the moving parts!
Observe maximum weights: The Next Level Racing Traction Plus System has a maximum payload of 235 kg. The Next Level Racing Motion Platform V3 allows a max. payload of 130 kg (incl. seat and seat-mounted accessories). Therefore, make sure that you do not exceed both values. The total weight of the cockpit depends on the accessories (controls) you have mounted and the driver's weight. Depending on the configuration, we recommend not exceeding the driver's face of 100 kg.

The set is explicitly ordered and preconfigured for you. Therefore we cannot grant you the right of withdrawl to this article. Please consult us before buying! The pictures partly show the prototype with optional accessories.

Attention: This Built-To-Order contains the following features. Certain items (such as the GTTrack cockpit, the actuators and the F2M adapter set must not be removed in order not to lose the price advantage of the bundle price! So please pay attention to the price development in the shopping cart!

• Fanatec Clupsport V2 Cockpit
• Next Level Motion Platform V3
• Next Level Traction Plus System
• Force2Motion ProSimu 4 DOF System with Force2Motion-Adapter-System Size X
• 2x Next Level Racing floor mat (Note: When using the Next Level Traction Plus System, you will need two mats!)
• Buttkicker incl. control unit and external USB sound card
• Force2Motion cable management

You can find more articles and options in the Ready2Race/Ready-To-Race single products section.


Assembly time: The complete assembly of the beast takes 2-3 days if you know what you are doing and read and understand the manual. If you don't feel like reading our manual (please download and read under "Documents" before buying) and the manuals for the individual products, have two left hands or are simply too impatient, then please use our assembly service (conditions on request) or leave the kit alone! This prevents frustration on both sides ;-) !

Force2Motion 8DOF - Motion-Simulator - Built-to-Order "The Beast"


Important note: Due to product discontinuation by the manufacturer, this product is no longer available in this form. An improved replacement based on the Qubic system is now available.


The ultimate combination of Seat-Mover and Full-Motion-Cockpit with Traction Loss

Attention: Do not be put off by the price shown! This bundle contains all possible options and combinations you can choose from. The actual price will be significantly lower after your selection in the shopping cart!

Our innovative Force2Motion 8DOF cockpit, exclusively manufactured in this combination, combines the GTTrack cockpit with Motion Platform V3 (Seat Mover) and the Traction Plus system (for oversteer and understeer effects) from Next Level Racing with the Cockpit Mover based on the ProSimu T1000 4M. As the "cream on top", a butt kicker is mounted, which transfers the vibrations from the engine, speed limiter and curb effects tactilely into the seat and thus onto the driver's body.

This turns the system into the ultimate racing and/or flying cockpit with 8 DOF. This product idea arose from the idea of putting together a complete cockpit with all conceivable options for our showroom in order to show our customers the respective effects of the individual motion systems on one system. After we had gained sufficient experience with the prototype, we completely redesigned the adapter system for combining the two worlds and had it manufactured in Germany. The adapter system is so modular that it is 100% compatible with the Next Level Racing Traction Plus system and can therefore be installed as an add-on between the GTTrack cockpit and Traction Plus. The adapter system can also be used to mount other cockpits than the GTTrack on the Next Level Racing Traction Plus system. For example, there is already an aluminium plate pre-drilled for RSeat RS1 and S1 cockpits, which can of course also be used for other cockpits and do-it-yourself projects by drilling appropriate holes.

The Beast: All-In-On for testing in our showroom

Fast Facts:

• Cockpit with 4DOF plus Next Level Racing Motion Platform (Seat-Mover) with 2 DOF and Traction Plus (2 DOF)
• 8 actuators plus Buttkicker
• NLR GTTrack cockpit with seat adjustment
• Racing seat (standard NLR - optional at extra charge ProSimu racing shell rigid)
• Safety belts
• Force2Motion adapter systems (optionally with or without mounting plate for third-party cockpits)
• All necessary electronics, cables and screws including cables (power supply, signal converter USB)
• Plastic housing and steel/alu frame
• Very resistant paint (colour powder heated to 200 ° C on the structure)
• Made of square tubes, ultra-precise laser cutting, allows maximum rigidity.
• Compatible with many accessories and devices: Thrustmaster, Fanatec etc. (not included)
• Power supply: Standard Schuko plug 110-240V - Power consumption approx. 500 Watt
• Space requirements (footprint): length approx. 200 cm x width 120 cm (+ space for entry) x height 170 cm (upper edge of seat) - available width between actuators: 64 cm (max. cockpit width)

Windows - PC required ! No support for Playstation, Xbox and other consoles! - Software (Simtools) included!

For details of the Next Level Motion platform see the corresponding article description

Attention: This is not a toy and not a ready assembled product! The offered article is a kit for a motion cockpit. For assembly, manual skills and tools (including ratchet set, Allen spanner, open-end spanner set and socket spanner 22 or 24mm) are required. For the drive, actuators from the industrial control system are used, which are not designed for home use. The installation and connection of the electrical components may only be carried out by appropriately qualified persons. Operation is at your own risk. Make absolutely sure that no small children or pets can get near the moving parts!

The set is explicitly ordered and preconfigured for you. Therefore we cannot grant you the right of withdrawl to this article. Please consult us before buying! The pictures partly show the prototype with optional accessories.

Attention: This Built-To-Order contains optional equipment features where you have to decide between several options or it contains options which you can remove in the shopping cart. Certain items (such as the GTTrack cockpit, the actuators and the F2M adapter set must not be removed in order not to lose the price advantage of the bundle price! So please pay attention to the price development in the shopping cart!

• Next Level Racing GTTrack Cockpit
• Next Level Motion Platform V3
• Next Level Traction Plus System
• Force2Motion ProSimu 4 DOF System with Force2Motion-Adapter Plate (fits on Next Level Racing Traction Plus and GT Track)
• 2x Next Level Racing floor mat (Note: When using the Next Level Traction Plus System, you will need two mats!)
• Next Level Racing Triple Monitor Stand or Single Monitor Stand (to choose from)
• Next Level Racing Free Standing Keyboard and Mouse Stand
• F2M keyboard with trackball (german layout or choose englisch in your comments)
• Monitor(s) 55" Smart TV incl. HDMI or DP cable category "Gaming Top" or "Gaming Entry" (to choose from)
• Force2Motion Gaming PC category "High-End" or "Standard" to choose from (installation language German or choose english in your comments )
• Fanatec Podium Wheelbase DD1 or DD2 (to choose from)
• Fanatec Formula Wheel V2
• Fanatec Clubsport Pedals V3 Vertical or Inverted (to choose from)
• Fanatec H-Shifter
• Fanatec Handbrake
• Surround System 5.1 incl. speaker stand
• Buttkicker incl. control unit and external USB sound card
• Next Level Combat Flight Pack
• Force2Motion cable management

Further articles and options see shopping cart (to select or deselect)

Force2Motion adapter for Qubic BT1 Belt-Tensioner to NLR Motion Platform V3



In combination with the BT1V3 adapter developed by us, the Seat Belt Tensioner can be mounted on a Next Level Racing V3 as well as on practically any other seat console. The function of a seat slider for longitudinal adjustment of the seat is fully retained.

Watch the video (sorry German version only)

Scope of delivery:

• 1x Force2Motion adapter for Qubic BT1 Belt-Tensioner
• Screw set

Motion platform, belt tensioner, seat slider etc. NOT included.
Attention: Does not fit the Qubic CH1!

Force2Motion Bundle Qubic Systems BT1

The bundle contains:

• Motion-Systems Qubic System - Belt Tensioner BT1
• Motion-Systems Qubic System - Motion Lock für Seat Belt Tensioner
• Sicherheitsgurt 6-Punkt schwarz
• Force2Motion Adapter für Qubic BT1 Belt-Tensioner an NLR Motion Platform V3 Motion Platform V3, Force2Motion Seatframe oder andere Sitzkonsolen

Price advantage when ordering all four items without modification in the basket!

Motion-Systems Qubic System - QS-210-2.5DOF Motion System - Set

About QS-210

The QS-210 motion system is designed as a more compact iteration of the Qubic System QS-220 industrial-grade linear actuators. This motion set is linear, efficient, easy to connect, and requires no maintenance. The motion system shares the same features as the linear actuators utilized in Qubic System motion cockpits, particularly the attributes of low latency time and real-time vibrations. Tailored for dedicated sim racers and drivers, the QS-210 motion system includes additional sets of brackets that enable racers to install actuators in the most popular aluminum profile based cockpits available on the global market.

Automotive grade performance for your sim racing experience - proudly made in poland

The QS-210 motion system is a high-end motion set designed to deliver an ultra-realistic simracing experience. It incorporates advanced haptic feedback technology that provides precise force feedback, enhancing the sense of immersion. The system comes with dedicated software for customization and frequent updates, making it a favorite among simracing enthusiasts.

QubicManager software is free of charge and develops in house by Motion Systems engineers. QS-210 takes washout filter’s approach to signal processing and motion control to deliver the next level of immersive driving experience. Every bump, road structure, braking, accelerating and vehicle movement is captured and reproduced within 60 mm/ 2.36” of the available actuator’s stroke. Qubic System products are well-supported allowing users to stay engaged with the latest advancements in simracing technology.

60 mm actuator stroke - realism and immersion of the simulation

In sim racing, the actuator stroke refers to the range of motion or travel that a motion actuator or motion platform is capable of producing. Motion actuators are devices that are often used in sim racing setups to provide physical feedback and simulate the sensations of acceleration, braking, cornering, and other movements experienced in real-world driving.

The actuator stroke determines how far and in what directions the motion platform or seat can move. For example, it may refer to the maximum distance the seat can move forward and backward, tilt side to side, or pitch up and down. The stroke length can vary depending on the specific motion platform or simulator hardware being used. Having a sufficient actuator stroke is important in sim racing because it directly impacts the realism and immersion of the simulation. A 60 mm/2.36 in stroke allows for a wider range of motion and can provide a more accurate representation of the forces experienced in a real vehicle. This can make the driving experience in the simulator feel more authentic and responsive, enhancing the overall immersion for the sim racer.

Plug & Play - simple and hassle-free setup process

The installation of the QS-210 motion system is exceptionally straightforward. You can have it up and running within minutes. attaching the four actuators to your aluminum cockpit is a breeze, thanks to the included mounting brackets that come with the motion set. to streamline the process further, you can easily download the qubic manager software with just one click, and it’s completely free of charge. utilizing the step-by-step tutorial, you’ll effortlessly configure the system to your specific preferences. The motion system only requires a power supply of 115/230 vac. In practically no time at all, you’ll be fully prepared to engage in thrilling races.

Enhance stability - precision and customization in simracing

The QS-210 motion set equipped with dedicated brackets allowing precise customization for an immersive racing adventure. These adaptable brackets seamlessly integrate actuators into popular aluminum based cockpits, delivering unwavering stability and an exhilarating virtual racing experience.

In-house software - even most advanced hardware is nothing without good software

Qubic Manager is a in-house professional and specialized software for motion platforms. It is plug-and-play compatible with all major racing and flight titles on PC and is continually updated to support new titles as they are released. The Qubic Manager is a powerful engine, yet it’s simple to use, allowing you to easily adjust levels of motion, bumps, roll, and pitch with a click of a button. This software caters to users of all skill levels. It features an intuitive interface with clear menus and guided setup for beginners. Quick start wizards and predefined profiles simplify the initial configuration. Troubleshooting guides assist with common issues.

Advanced users benefit from an in-depth editor, scripting support, and multi-device integration capabilities. It seamlessly integrates with QS products, enhancing functionality. A vibrant online community shares tips and scripts for collaboration. This decade-developed software empowers both beginners and experts. It’s a versatile tool for enhancing productivity, automation, and control, with a strong Qubic ecosystem.

VR ready - unlocking seamless virtual reality with motion compensation

Qubic Manager software is ready to embrace virtual reality. This means that users can enjoy a complete and authentic simulation experience without integration hassles, thanks to perfect compatibility with VR technology. With Qubic System’s VR Ready software, simulations become more immersive than ever. Realistic sound effects, seamless movements, and impeccable synchronization with visual elements create unforgettable journeys in the virtual world. The entire experience becomes smooth and effortless, allowing users to focus on the sensation itself rather than technical intricacies. Qubic System redefines simulations, enabling entry into a new dimension of simulated travels through the built-in VR HeadWay 2.0 functionality.

Responsive revolution - linear actuators with a latency time of less than 8ms.

Low latency in simracing is crucial for several key reasons:

• Realism: Simracing aims to replicate real-world racing closely. Low latency ensures the virtual car responds in real-time, enhancing immersion by mimicking a real car’s responsiveness.
• Precise Control: Racing games require precise control over steering, braking, and acceleration. Low latency ensures minimal delay in translating your inputs to the game, enabling accurate and responsive control, especially in fast-paced races.
• Safety: In simracing, accidents can happen. Low latency allows quick reactions to track changes, reducing the risk of collisions or losing control.
• Competitive Advantage: Milliseconds matter in simracing competitions. Low-latency setups give drivers a competitive edge by enabling faster reactions and split-second decisions.
• Real-Time Feedback: Low latency provides immediate feedback from input devices, helping drivers understand their vehicle’s behavior and make adjustments during races.
• Consistency: Minimal delay maintains consistent lap times and performance, allowing simracers to execute precise maneuvers consistently.
• Enhanced Experience: Low latency complements high-quality hardware and software, ensuring a seamless interface and an enjoyable racing experience.
• Training and Skill Development: Simracing serves as a training tool for real-world racing. Low latency lets drivers practice and refine skills in a realistic virtual environment, translating into improved on-track performance.

Qubic ecosystem - all-in-one

The Qubic Ecosystem encompasses a collection of various products and one software to control all of the devices, even 3rd party accessories. Within this product ecosystem, a range of motion systems are created to work with one another, resulting in a seamless and integrated racing experience.

Teh QS21ß set is a perfect motion base for most aluminum profile based cockpits available on the global market (using brackets). QS-210 works also with QS-CH2 motion platform (Only as 3DOF set, not with pivot bar!).The concept of the Qubic System product and software ecosystem underscores the idea that the whole system works together synergistically to offer users enhanced value and functionality.

With Motion-Systems Qubic System - QS-Pivot to a 2.5 DOF-System

QS-Pivot is an innovative accessory designed for users seeking the intense sensations typically found in high-end simulators. When combined with QS-210 or QS-220 actuators, it creates a unique 2.5 DOF* configuration that delivers full immersion in driving simulation.

We recognize that many individuals cannot afford the one-time expense of implementing a 3DOF (4 actuators) system for their simulator. To address this, we are introducing the option to take the first step with just 2 actuators using an additional accessory: the pivot leg, which we are thrilled to add to the Qubic System lineup.

Interestingly, if the QS-PIVOT is mounted sufficiently far forward, this setup will create the impression of an additional HEAVE axis, as the motion from the PITCH axis will be so optimized that it feels like translational (vertical) motion to the human vestibular system. Thus, with just 2 actuators combined with the pivot leg, users can achieve a “2.5 DOF” sensation, which may be an excellent starting point for many enthusiasts.* Heave motion pattern combined from pitch axis.

What's included:

QS-210 2.5DOF MOTION Set consists:

• 2x – linear actuator with stabilization plates
• 2x – power cabinet (control module)
• 2x – mounting brackets (set of 2)
• 1x – motion lock cable (up-link/down-link) – 2 m long
• 1x – power cable
• QS-PIVOT
• QS-MC6 Controller Set with 1x – motion lock with additional 2 m long cable

Can be upgraded to a full 3DOF set with an additional optional QS-2102DOF set (not included)!

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - QS-220-2.5DOF Motion System - Set with 2 Aktuators and 1 Power Cabinet and Pivot-Bar

About QS-220

Linear actuator technology by Motion Systems allows to develop highly realistic applications with detailed motion textures, velocity, suspension interaction feedback, engine vibrations, tactile feedback, haptic system and vehicle dynamics. Innovative technology, modular and compact design, as well as the quiet operation makes the QS-220 as a perfect motion base not only for professional application but also for home users in various types of cockpits. Additional sets of QS-220 can be configured as a 4 and 6 actuated system to provide 3 / 4 / 6 DOF using dedicated cockpits from Qubic System product line.

By using dedicated software Qubic Manager the user can use several sets to create the most realistic simulation that immediately responds to onscreen situations to deliver real life experience in gaming or VR
applications. Motion Systems is a global leading motion platforms brand for professionals and the most demanding home users. For over 10 year the company has been designing and providing bespoke motion solutions for industry and cutting edge technology for racing and flight simulation.

Fast Facts - Hardware:

Patent pending technology of QS-L1 linear actuators from Qubic System Line allows to develop highly realistic applications with detailed effects from simulation telemetry. Motor drivers have
been designed by Motion Systems company to do just one job, to control motors in vehicle simulator applications and they are exceptionally good at it.

Included power cabinet (control module) QS-SB2 is responsible for the power distribution and communication to handle telemetry signal processing where motion controller dispatches the commands
to drivers which parse the incoming command as soon as the command arrives. Control module sets the motion and vibration cues for each single actuator. The driver works with both 115V and 230V power
network without any adapters or voltage converters.

General specification of QS-220 set:

• Architecture: 2 / 3 / 4 / 6 DOF (depending on user configuration and number of modules)
• Actuator stroke: 100 mm | 3.93 in
• Maximum velocity:
  • Q-Mode (230V): 800 mm/s
  • Performance Mode (115V/230V): 400 mm/s
  • Heavy Duty Mode (115/230V): 300 mm/s
• Maximum acceleration:
  • Q-Mode (230V): 0.8G*
  • Performance Mode (115V/230V): 0.7G*
  • Heavy Duty Mode (115/230V): 0.4G*
  • *value of acceleration is limited for safety reasons.
• Recommended payload in 3DOF (2x QS-220) configuration:
  • Q-Mode: 200kg
  • Performance Mode: 250kg
  • Heavy Duty Mode: 350kg
• Maximum control frequency: 1000 Hz
• Vibrations frequency range: 0-100 Hz
• Latency: <8 ms
• Product weight: 30 kg | 66 lb
• Total length: QS-L1: 90 mm | 3.55 in, QS-SB2: 385 mm | 15.16 in
• Total width: QS-L1: 90 mm | 3.55 in, QS-SB2: 300 mm | 11.81 in
• Total height: QS-L1: 553-653 mm | 22-26 in, QS-SB2: 88 mm | 3.46 in
• Cable length (QS-L1 actuator - QS-SB2 Power cabinet): 1150mm | 45.2 in
• Power supply requirements: 115/230 VAC Single Phase
• Average power consumption in 3DOF configuration:
  • Q-Mode: 260W (230V)
  • Performance Mode: 280W (230V), 270W (115V)
  • Heavy Duty Mode: 436W (230V), 462W (115V)
• Peak current for breaker specification in 3DOF configuration:
  • Q-Mode: 5.17A (230V)
  • Performance Mode: 4.55A (230V), 7.35A (115V)
  • Heavy Duty Mode: 5.88A (230V), 9.89A (115V)
• Connection: USB

Fast Facts - Software:

Even most advanced hardware is nothing without good software. Qubic Manager by Motion Systems company is professional and specialized software for the platform and is "click and play" compatible with
all major racing and flight titles on PC and constantly updated to support new applications as they are released. Gives user possibilities of motion adjustments, motion post-processing, extensive diagnostic or
easy and fast use of predefined profiles. The Qubic Manager is a powerful engine, yet it’s simple to use meaning you can adjust levels of motion, bumps, roll and pitch with a click of a button.

Qubic Manager software license is free-of-charge.

Few main features:

• Over 80+ already integrated and supported racing games and professional simulation applications.
• Included VR Headway technology uses advanced mathematic formulas to calculate necessary compensation and applies it to the VR headset at runtime. It eliminates platform movements from the VR tracking system causing your experiences to be more immersive, authentic and has huge impact on VR sickness compensation.
• The motor control algorithm has been developed to be used strictly in simulation application. The positioning signal is analyzed and preprocessed directly by the driver, so it is possible to change all driver parameters at basically zero cost (time / latency). Drivers parse the incoming command as soon as the command arrives. It also allows to append different types of vibrations (per actuator) on driver level.
• Motion sickness compensation thanks to telemetry data provided in real time directly by the game’s engine and immediately injected to the hardware to perform.
• Equipped with Tactile Audio Based Feedback System that can use tactile trans-ducers (Buttkicker) connected to a seperate sound card to generate additional effects on your cockpit (Buttkicker and additional Soundcard not included - available seperatly).
• Thanks to having full control of the technology Motion Systems company can change control algorithm source code, introduce new parameters and features without waiting for 3rd party vendors. Simple software update can introduce new features to the customers.
• Motion SDK (FSM or FSDI) for software developers is also available as an extra option. That powerful interface allows to add a motion platforms support to any application or game.
• … and many more!



With Motion-Systems Qubic System - QS-Pivot to a 2.5 DOF-System

QS-Pivot is an innovative accessory designed for users seeking the intense sensations typically found in high-end simulators. When combined with QS-210 or QS-220 actuators, it creates a unique 2.5 DOF* configuration that delivers full immersion in driving simulation.

We recognize that many individuals cannot afford the one-time expense of implementing a 3DOF (4 actuators) system for their simulator. To address this, we are introducing the option to take the first step with just 2 actuators using an additional accessory: the pivot leg, which we are thrilled to add to the Qubic System lineup.

Interestingly, if the QS-PIVOT is mounted sufficiently far forward, this setup will create the impression of an additional HEAVE axis, as the motion from the PITCH axis will be so optimized that it feels like translational (vertical) motion to the human vestibular system. Thus, with just 2 actuators combined with the pivot leg, users can achieve a “2.5 DOF” sensation, which may be an excellent starting point for many enthusiasts.* Heave motion pattern combined from pitch axis.

What's included:

QS-220 2.5DOF MOTION Set consists:

• 2x – linear actuator QS 220 with stabilization plates
• 2x – power cabinet (control module)
• 2x – mounting brackets (set of 2)
• 1x – motion lock cable (up-link/down-link) – 2 m long
• 1x – power cable
• QS-PIVOT
• QS-MC6 Controller Set with 1x – motion lock with additional 2 m long cable

Can be upgraded to a full 3DOF set with an additional optional QS-220-2DOF set (not included)!

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - CH2-220.3DOF.BT1 Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-220 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market / or 1 pcs of 2m long cable for USA market
• 4x QS brackets (set of 2) for mounting on aluminium profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - CH2.210.3DOF.BT1.FGT.SET Ready2Race-Bundle

What is included in the package:

• CH2 Platform
• 4x QS-210 - linear actuator with cup holder
• 2x QS-SB2 - power cabinet (control module)
• 1x QS-SBML-2 - motion lock cable (up-link/down-link) - 2 m long
• 3x Power cable - 1 pcs of 1,8m long cable for EU market
• 4x QS brackets (set of 2) for mounting on aluminum profile cockpits (Note: For mounting an FGT cockpit or similar, please also consider the specially widened F2M brackets as an option for an additional charge)
• QS-MC6 motion controller set - single unit required to control up to 4 sets of QS (not included - see separate product)
• BT1 Seat-Belt-Tensioner with accessories
• Force2Motion Adapter for Qubic BT1 Belt-Tensioner
• F2M-Adaptersystem FGT-Elite-Qubic
• Next Level Racing FGT 160 - Wheel Plate Edition

Attention: Special price as a package! If you remove individual mandatory components of the package in the shopping cart, you may lose the price advantage. Therefore, please pay close attention to the prices in the shopping cart!

Motion-Systems Qubic System - Motion Lock for Seat Belt Tensioner

Emergency stop switch (Motion Lock) - recommended Option for Seat Belt Tensioner Qubic BT1
(not required if other Qubic systems are present, as the system can be controlled via an (existing) motion lock switch)

F2M adapter system FGT-Elite-Qubic

With the F2M adapter system FGT-Elite-Qubic it is possible to mount the Qubic actuator system QS210 or QS220 on the Next Level Racing FGT Elite cockpit

The F2M base plate is mounted under the Next Level Racing FGT Elite cockpit and closes off the cockpit at the bottom. The control units for the Qubic QS210/QS220 can be mounted on the underside of the plate using pre-drilled holes.

With the extended actuator brackets also included, the actuators can be mounted on the cockpit offset by 40 mm so that they do not collide with the pedal plate of the FGT-Elite/FGT 160.

Attention: When mounting the system on a Qubic CH2, the Qubic CH2 cockpit adapter set is also required (see https://www.force2motion.de/de/cockpit-adapter-set-qubic-ch2.html)

The plate consists of a 5 mm thick folded aluminum sheet, powder-coated in black fine structure, with corresponding holes for attachment to the aluminum profiles of the cockpit. The set is supplied with screws and I-profile M8 slot nuts. The actuator brackets consist of black powder-coated brackets with corresponding holes, e.g. for the FGT-Elite cockpit (80/100 and 160 aluminum profiles).

Scope of delivery:

• Base plate black powder-coated 5 mm drilled for NLR FGT Elite
• T-nuts
• screws
• 4x double sets of actuator brackets for wider actuator mounting - A double set consists of two identical / mirrored brackets.
•  Any controllers and accessories shown are NOT included!

F2M Adapter System FGT-Elite-Qubic – Base Plate

The F2M Adapter System FGT-Elite-Qubic allows the Qubic actuator system QS210 or QS220 to be mounted on the Next Level Racing FGT Elite cockpit.

Please refer to the relevant product description for the complete system. This item contains only the base plate with the necessary screws and slotted nuts





Safety Harnesses 6 point
