Active Belt-Tensioner

Motion-Systems Qubic System - Belt Tensioner BT1 - Multi-purpose, dual channel, direct drive seat belt tensioner

Note: All BT1 units supplied by us have the ‘new’, quieter power supply unit. Please note: Delivery does not include an IEC power cable – please order separately (only available from us for German and compatible sockets with type E+F safety plugs) or purchase one yourself that complies with the standards in your country (See image ‘Power Requirements’ for requirements)!

The Polish manufacturer Motion Systems, which has developed the “Qubic System” motion platforms among other things, has launched a new sensation: the QS-BT1 belt tensioner.

And we are rather proud of this development ourselves, as Force2Motion was a driving force behind the creation of this add-on. With input from the racing and flight sim communities, we have persistently campaigned for Motion Systems to build what we consider to be an indispensable extension for the Qubic systems. And now Motion Systems has unveiled this product, which can also be fitted to many stand-alone cockpits without motion. And of course, it’s a great addition for those who already have ‘everything’. Well done, guys!

In combination with the BT1V3 adapter we developed, the Seat Belt Tensioner can be mounted on both a Next Level Racing V3 and virtually any other seat console. The function of a seat slider for longitudinal seat adjustment is fully retained.

Watch the video (sorry German version only)

More info and photos: https://qubicsystem.com/product/qs-bt1/# - Please be sure to follow the instructions on installation (seat height, belt openings on the seats) etc.!

About:

Powered by the same technology as the stunning QS-220, the QS-BT1 is a multi-purpose dual channel direct drive seatbelt tightener that enhances immersion in racing simulations like no other device in its class and price range. It not only complements the force feedback of the direct drive steering wheels, but also enhances the overall experience of the already highly immersive QS motion platforms and can even be used as a standalone, independent device if required.

Simulation of braking, lateral acceleration, cornering at high speed, wheel lock and loss of traction are among the key features of QS-BT1. Asymmetric engine vibrations and road effects such as rumble strips are also available for games that support them. Although QS-BT1 was mainly developed for racing simulations, with its 200 N force per channel it can also be successfully used in flight simulators to give you the feeling of gigantic forces during high acceleration manoeuvres.

Specifications:

• Power source: 4A/115VAC, 2A/230VAC
• Rated power: 321 W
• Inrush current: 20A/115VAC, 40A/230VAC
• Protection class: 1
• Interface: USB
• Number of independent channels (seat belts): 2
• Tensile force: 20.5 kg/45 lbs/200 N per channel
• Storage temperatures: +4°C to +45°C
• Full performance temperatures: +5°C to +35°C
• Computer compatibility: Windows PC
• Supported effects: Depending on the game
• Multifunctional RGB
• Maximum length of USB cable: 3m
• Maximum length of motion lock cable: 3m (motion lock optional)
• Compatibility with motion platforms: QS, PS, HS [1]

Dimensions:

• Main dimensions: 561 x 99 x 138 mm / 22.13 x 3.90 x 5.43 inches
• Weight of the main unit: 12 kg / 26.46 lbs
• Weight of the power supply unit: 2.8 kg / 6.17 lbs
• Dimensions of the packaging box: 660 x 255 x 180 mm / 25.98 x 10.04 x 7.09 in
• Weight of the packaging box: 18kg / 39.68 lbs

Scope of delivery:

• 1x two-channel seat belt tensioner
• 1x power supply unit
• 1x cable set (without power cable!)
• 1x set of screws
• 1x universal bracket for aluminium profile

Optional accessories (recommended):

• Emergency stop switch (motion lock) - is not required if other Qubic systems are present, as the system can be controlled via an (existing) motion lock switch.
• Note: All BT1 units supplied by us have the ‘new’, quieter power supply unit. Please note: Delivery does not include an IEC power cable – please order separately (only available from us for German and compatible sockets with type E+F safety plugs) or purchase one yourself that complies with the standards in your country (See image ‘Power Requirements’ for requirements)!

Note: For the use of seat movers (such as the NLR Motion Platform V3), the QS-BT1 can only be installed on the upper frame of the motion platform near the pivot point and reduces the permissible user weight. A multi-point harness is required and is not included in the scope of delivery.



Force2Motion adapter for Qubic BT1 Belt-Tensioner to NLR Motion Platform V3



In combination with the BT1V3 adapter developed by us, the Seat Belt Tensioner can be mounted on a Next Level Racing V3 as well as on practically any other seat console. The function of a seat slider for longitudinal adjustment of the seat is fully retained.

Watch the video (sorry German version only)

Scope of delivery:

• 1x Force2Motion adapter for Qubic BT1 Belt-Tensioner
• Screw set

Motion platform, belt tensioner, seat slider etc. NOT included.
Attention: Does not fit the Qubic CH1!

Force2Motion Bundle Qubic Systems BT1

The bundle contains:

• Motion-Systems Qubic System - Belt Tensioner BT1
• Motion-Systems Qubic System - Motion Lock für Seat Belt Tensioner
• Sicherheitsgurt 6-Punkt schwarz
• Force2Motion Adapter für Qubic BT1 Belt-Tensioner an NLR Motion Platform V3 Motion Platform V3, Force2Motion Seatframe oder andere Sitzkonsolen

Price advantage when ordering all four items without modification in the basket!

Motion-Systems Qubic System - Motion Lock for Seat Belt Tensioner

Emergency stop switch (Motion Lock) - recommended Option for Seat Belt Tensioner Qubic BT1
(not required if other Qubic systems are present, as the system can be controlled via an (existing) motion lock switch)

Motion-Systems Qubic System - QS-BT1 to Next Level Racing® Motion Platform V3 Installation Kit

The QS-BT1 to Next Level Racing® Motion Platform V3 Installation Kit is a solution for connecting the QS-BT1 to the Next Level Racing® Motion Platform V3. Designed for a quick installation and stable connection between Motion Platform and QS-BT1 belt tensioner. Whether you are configuring new equipment or upgrading existing components, this bracket ensures a simple and hassle-free installation process.

Scope of delivery:

• Adapter set
• Set of screws

Please note: BT1 Belt-Tensioner, Cockpit etc. are NOT included.

Note: As this adapter is fitted directly to the V3, the use of a seat slider is not possible or only possible to a limited extent. The seat shifts in relation to the rigidly mounted BT1, which can lead to undesirable effects. Furthermore, no Buttkicker Gamer can be installed on the V3. There is a solution for both problems: If a seat slider is installed, we recommend using the F2M seat slider: Force2Motion adapter for Qubic BT1 Belt-Tensioner to NLR Motion Platform V3 Motion Platform V3

Motion-Systems Qubic System - QS-BT1 Installation kit for QS-CH1

The Motion-Systems Qubic System - QS-BT1 Installation kit for QS-CH1 is a solution for connecting the QS-BT1 to the Next Level Racing® Motion Platform V3. Designed for a quick installation and stable connection between Motion Platform and QS-BT1 belt tensioner. Whether you are configuring new equipment or upgrading existing components, this bracket ensures a simple and hassle-free installation process.

Scope of delivery:

• Adapter set
• Set of screws

Please note: BT1 Belt-Tensioner, Cockpit etc. are NOT included.

Safety Harnesses 6 point
